Canare

OFC GUITAR CABLE

Product Code: CA-GS4-BK200

Brand
Canare
RRP $760.00


Unit of Measure
EACH


1 Year
Technical Specifications
Brands Canare
  • Details
  • Downloads
Features
Miniature size 22 AWG version of GS-6. Good choice for short run unbalanced audio interconnects and general instrumentation cables.
  • Electronic Instruments.
  • Hi-Fi Interconnects.
  • Test Probes.
  • Audio Patch Cords.
  • AMP to Cabinet Leads.
  • Stays Flexible even in Sub-Zero Weather.
  • Oxygen Free Copper Conductor & Shield.
  • Reduced Microphonic Handling Noise.
  • Low Capacitance & Resistance.
MECHANICAL SPECIFICATIONS
Model Std. Lng.


ft.
(m)		 Wt
Std. Lng.

lbs
(kgs)		 Nom.
O.D.

in.
(mm)		 Jacket
Nom.
Thick.
in.
(mm)		 Brittle
Point

F°
(C°)		 No.
of
Cond.		 Insul.
Type*
Thick

mil		 Cond-AWG
(Qty./mil)
Cross Sec.
Area
mil.2		 Pitch
Twist
Quad
in.
(mm)		 Shield
Cover-
age
GS-4 656
(200)		 12
(5)		 .157
(4.0)
.028
(0.7)
 -56
(-49)		 1 PE
19.7		 OFC-#22
(50/3.94)
604.5		 -
 OFC>93%
Braid+
Carbon
Sleeve
*Dielectric Strength = 500V AC/1min. Insulation Resistance/3Mft = >1000M ohm.
**Effective AWG of combined twin conductors.

ELECTRICAL PERFORMANCE/QUAD
Model Cond.
D.C.R.
ohm/1000ft
(ohm/100m)		 Shield
D.C.R.
ohm/1000ft
(ohm/100m)		 Nom.
Cap.
***

1>pF/m		 Nom.
Cap.
†

pF/m		 Nom.
Imp.
ohm		 Nom.
Atten.
V/1000ft
(V/100m)		 Group
Delay
Time
nS/ft
(nS/m)
GS-4 <14.7
(<4.8)		 <9.8
(<3.2)		 - 154 - - -
***Capacitance between conductors.
†Capacitance between conductors to shield.
COLORS AVAILABLE
Model Black Blue Brown Gray Green Orange Purple Red White Yellow
GS-4 [+] - - - - - - - - - - - - - - - - - -
[+]=Standard Color, [o]=Available Color, "- -"=n/a
