Specifications

Directional pattern:	Cardioid
Principle of operation:	Pressure gradient
Cartridge type:	Pre-polarized condenser
Frequency range:	20 Hz - 20 kHz
Frequency range, ± 2 dB, at 30 cm:	40 Hz - 20 kHz
Sensitivity, nominal, ± 2 dB at 1 kHz:	10 mV/Pa; -40 dB re. 1 V/Pa
Equivalent noise level, A-weighted:	Typ. 18 dB(A) re. 20 µPa (max. 20 dB(A))
Equivalent noise level, ITU-R BS.468-4:	Typ. 25 dB
S/N ratio (A-weighted), re. 1 kHz at 1 Pa (94 dB SPL):	Typ. 76 dB(A)
Total Harmonic Distortion (THD):	< 1 % up to 139 dB SPL peak
Dynamic range:	Typ. 121 dB
Max. SPL, peak before clipping:	144 dB
Output impedance:	100 Ω
Minimum load impedance:	2 kΩ
Cable drive capability:	100 m (328 ft)
Output balance principle:	Impedance balancing
Common Mode Rejection Ratio (CMRR):	> 40 dB
Power supply (for full specifications):	48 V Phantom power (± 4 V)
Current consumption:	3.5 mA
Connector:	XLR-3M. Pin 1: shield, Pin 2: signal + phase, Pin 3: - phase
Color:	Matte black
Weight:	109 g (3.8 oz)
Microphone diameter:	19 mm (0.75 in)
Capsule diameter:	19 mm (0.75 in)
Microphone length:	35 mm (1.38 in)
Output voltage, RMS:	2.2 V
Polarity:	+V at pin 2 for positive sound pressure
Temperature range:	-40 °C to 45 °C (-40 °F to 113 °F)
Relative Humidity (RH):	Up to 90%
Matching tolerance:	± 1 dB
Phase deviation for kit:	< 10°

Brands	DPA Microphones
Series	d:dicate
