Features

• Second Generation amp modeler & effects processor with a pedalboard-friendly case
• Perfectly fits any pedalboard matrix when used as an effect pedal
• Enhanced Ampero sound quality brought by the more powerful tri-core DSP platform and ESS® Sabre® AD/DA
• Evolved CDCM HD & F.I.R.E. modeling system ensures high end tonal expressiveness and realistic playing experience
• 24-bit signal processing, up to 127dB dynamic range*
• 4-inch 800 x 480 dynamic touchscreen and newly designed UI for more intuitive control
• Highly customizable DUAL effect chain with multiple serial/parallel signal routing support
• Add ANY effect module you like to the effect chain
• Stereo I/O jacks and stereo FX Loop jacks for further routing/tonal possibilities
• Up to 12 simultaneous effect modules
• Upgraded effects library delivers 400+ effects
• CDCM HD & F.I.R.E. modeling effects including:
•  - 87 amp models
• - 68 cab models
• - A more precise cabinet-mic algorithm based on realistic studio recording data
• - New preamp models
• - Independent power amp simulation
• - 100+ legendary pedal models
• 60+ Hotone original effects (incl. high quality drive/dynamic/filter/mod/delay/reverb models and more)
• Dedicated IR loader module with 3rd party IR support, up to 50 custom IR slots
• 20 classic Celestion® speaker IRs included - Powered by Celestion® Digital
• Supports up to 2048 IR sampling points for better tonal resolution
• USB port for firmware upgrading, loading/editing/managing effects/IRs via free Win/Mac software or for use as an USB audio interface
• 8-in, 8-out USB audio interface
• Supporting Reamp function
• Ampero-style acoustic effects and presets
• Ampero-style input mode selections
• 300 presets (100 banks x 3 patches)
• Built-in stereo looper with max. 60 seconds recording time and undo/redo function
• 3 assignable footswitches with halo LEDs
• Customizable main display modes and theme colors
• Authentic stereo processing
• MIDI I/O jacks and EXP/CTRL jack for expanded controls
• Road-ready, light-weight aluminum casing
• 9-18V DC power supply

*Digital to analog; actual data may vary depending on usage scenarios

Specifications

• Effects Digital Audio Signal Processing: 24-bit depth, 44.1kHz sample rate
• Frequency Response: 20Hz – 20kHz ± 1dB
• Dynamic Range: Max. 127dB (digital to analog)
• Effects: 460 (incl. global EQ)
• No. of Effect Modules: 16
• Effects Slots: Total of 12 simultaneous effects slots
• Patches: 300
• Looper Time: Stereo 60 seconds
• Inputs:
• Two 1/4″ Tip Sleeve (TS) instrument jacks with individual input mode selector
• One 1/8″ Stereo Auxiliary In (Aux In) jack
• One 1/4″ Tip Ring Sleeve (TRS) expression pedal/momentary footswitch input (EXP/CTRL) jack
• One 1/4″ Tip Ring Sleeve (TRS) unbalanced stereo FX loop return jack
• One Standard 5 pin MIDI input jack
• Outputs
• Two 1/4″ Tip Ring Sleeve (TRS) balanced stereo output jacks
• One 1/4″ Tip Ring Sleeve (TRS) unbalanced stereo FX loop send jack
• One 1/8″ stereo headphones output jack
• One standard 5 pin MIDI output jack
• Input Impedance
• Input: E.GT: 1MΩ; A.GT: 4.7MΩ; LINE: 10kΩ
• FX Loop Return: 100kΩ
• Aux In: 10kΩ
• Output Impedance
• Output: 1KΩ
• FX Loop Send: 1KΩ
• Headphones: 47Ω
• Input Level:
• Input: -17.78dBu (Nominal); 14.5dBu (Max)
• FX Loop Return: -17.78dBu (Nominal); 14.5dBu (Max)
• Aux In: -17.78dBu (Nominal); 20dBu (Max)
• Output Level:
• Output: -11.76dBu (Nominal); 26.25dBu (Max)
• FX Loop Send: -17.78dBu (Nominal); 14.5dBu (Max)
• Headphones: -7.4dBu (Nominal); 18.3dBu (Max)
• Screen: 4″ 800 x 480 Color Dynamic Display Touch Screen
• USB Port: USB 2.0 Type-C port, supports USB Audio 2.0
• Impulse Response/IR processing: Supports 24-bit/44.1kHz Mono WAV files, 1024 and 2048 points; Supports up to 50 user IRs
• Power Requirements: 9-18V DC Center Negative
• Current Consumption: 800mA Max (9V DC)
• Dimensions: 185mm(W) × 145mm(D) × 58mm(H)
• Weight: 1050g
