Apollo Series Conference Speakerphone

SKU: APO-100-UC

The APO-100-UC is the entry level solution in the Apollo series of unified communication products. The APO-100 is designed for small meeting rooms and huddle spaces. Simply connect the included USB cable to any laptop and instantly have access to a premium conference speakerphone, no drivers or software required. The APO-100 also allows video passthrough via USB. The supplied USB-C cable can be used natively with USB-C equipped devices, or with a standard USB-A 3.0 port using Display Link technology. Use the capacitive touch buttons on the top of the speakerphone to control volume, mute the microphone and even mute the video from your laptop, tablet, or smart phone.

SPEAKERPHONE
All Apollo series products feature a premium 360° omni-directional microphone array with echo cancellation, ensuring you can be heard loud and clear in every meeting. The powerful 10-watt speaker provides crystal clear audio delivery, even in the largest rooms.

DISPLAY LINK
Display Link technology allows the USB-C connection to support both native USB-C source devices and standard USB-A connections from laptops for video transmission and data.

MODERN DESIGN
A striking, and distinguishable appearance lets the Apollo sit comfortably atop a conference table in the most sophisticated boardrooms and meeting spaces.n video sources and modes.

CAPACITIVE TOUCH
Intuitive capacitive touch buttons provide volume control, mic mute, and video mute for your meeting. An LED ring on the top of the speakerphone provides real-time feedback of volume level and mute status.

Features

• 360° omni-directional microphone array with echo cancellation
• Powerful 10-watt speaker providing crystal clear audio delivery
• Capacitive touch volume and mic control buttons
• LED feedback ring for volume level and mute status
• Real-time LED indication of mic pick-up direction
• Simple plug and play design using a single USB connection
• Compatible with both USB-C and USB-A equipped computers with the supplied USB cable and adapter
• Video mute button allows content being shared from computers to be turned off easily if sensitive content needs to be viewed
• Native USB-C connection provides up to 60w device charging for laptops or tablets
• Native USB-C connection supports up to 4K 30 4:4:4 8bit content while USB-A Display Link connection supports up to 1080p 60
• Compatible with all major conference platforms including Microsoft Teams, Zoom, Skype, BlueJeans, Cisco WebEx and more!

Specifications

AUDIO AND VIDEO

• Inputs:
  • 1x USB-C
  • 1x USB 3.0 Female Device Port
• Outputs:    1x 19-pin HDMI type A
• Video Resolutions (Max):
  • USB-A Display Link & Wireless Casting: 1920x1080p @60Hz 8bit
  • Native USB-C: 3840×2160 @30hz 8bit 4:4:4
• Supported Standards:    RGB | USB
• Maximum Pixel Clock:    300 MHz

SPEAKERPHONE

• Microphone:
  • 4 x Omni-Directional Mic Array with Echo Cancellation
  • Pick-up Range: 5m/16.4ft
  • Frequency Response: 100Hz ~ 20KHz
  • Sample Rate: 16bit 48KHz
• Speaker:
  • 10 watts
  • 78 dB @ 1.5m/4.9ft
  • Sample Rate: 24bit 48Khz
• Control:    Capacitive touch volume +/- and microphone mute buttons

COMMUNICATION AND CONTROL

• USB:
  • USB-C: USB 3.2 Gen 2×1 | Max Bandwidth: 5Gbps (60w max charging)
  • USB-A 3.0 | Max Bandwidth: 5Gbps
  • USB-B 2.0 Mini: 480Mbps (USB over HDBT is limited to 190Mbps)

POWER

• Power Supply:    24V DC 5A
• Max Power Consumption:    Max: 10w | Max with USB-C charging: 70w

ENVIRONMENTAL

• Operating Temperature:    +32°F ~ +104°F (0°C ~ +45°C) | 10% ~ 90% non-condensing
• StorageTemperature:    -4°F to ~ 140°F (-20°C ~ +70°C) | 10% ~ 90% non-condensing
• Maximum BTU:    Standard: 34 BTU/hr

DIMENSIONS & WEIGHT

• Length x Width x Height:    Corner to corner (widest point): 266.7mm/10.5inHeight: 106.6mm/4.2in
• Weight:    1.98kg/2.4lbs

REGULATORY

• Safety and Emission:    CE | FCC | RoHS | EAC | RCM
