Features

✪ Second Generation amp modeler & effects processor with stage-friendly features

✪ Ampero II's iconic tri-core DSP platform and ESS® Sabre® AD/DAs providing musical, lively Ampero sound

✪ Evolved CDCM HD & F.I.R.E. modeling system ensures high end tonal expressiveness and realistic playing experience

✪ 24-bit signal processing, up to 127dB dynamic range*

✪ A larger, sharper 5-inch dynamic touchscreen and newly designed system UI for smoother, more intuitive, and more convenient interaction

✪ Highly customizable DUAL effect chain with multiple serial/parallel signal routing support

✪ Add ANY effect module you like to the effect chain

✪ Stereo I/O jacks and stereo FX Loop jacks for further routing/tonal possibilities

✪ Input R with built-in mic preamp and phantom power for adapting both dynamic/condenser microphones

✪ Up to 12 simultaneous effect modules

✪ Upgraded effects library delivers 460+ effects, including Hotone's next-gen higher-quality algorithms

✪ CDCM HD & F.I.R.E. modeling effects including:

    - 90+ amp models

    - 68 cab models

    - A more precise cabinet-mic algorithm based on realistic studio recording data

    - Independent preamp models

    - Independent power amp simulation

    - 100+ legendary pedal models

✪ 60+ Hotone original effects (incl. high quality drive/dynamic/filter/mod/delay/reverb models and more)

✪ Dedicated IR loader module with 3rd party IR support, up to 50 custom IR slots

✪ 20 classic Celestion® speaker IRs included - Powered by Celestion® Digital

✪ Supports up to 2048 IR sampling points for better tonal resolution

✪ Bluetooth® 4.2 dual-mode module for audio playback and remote control via iOS/Android app; supports Bluetooth® MIDI

✪ Free Win/Mac/Android/iOS software for firmware upgrading, loading/editing/managing effects/IRs, etc.

✪ 8-in, 8-out USB audio interface with 44.1 to 192kHz sample rate switching, supports Reamp function

✪ Built-in acoustic effects and presets

✪ 300 presets (60 banks x 5 patches)

✪ Built-in stereo looper with max. 60 seconds recording time and undo/redo function

✪ 5 different input modes with electric guitar/acoustic guitar/mic/line input support

✪ Independent BAL/UNBAL/Phones output processing for independent output volume control or different signal outputs

✪ 8 assignable footswitches with multicolor halo LEDs, with two working modes and customization support

✪ Scene function providing 5 scenes in a patch – switch effect on/off and different parameters with no latency

✪ Built-in multi-function color LED strip lights

✪ Customizable main display modes and theme colors

✪ Authentic stereo processing

✪ MIDI I/O jacks and dual EXP/CTRL jacks for expanded controls

✪ Constant firmware updates based on user feedback

✪ Future new features available (e.g. Wi-Fi)

✪ Road-ready, light-weight aluminum casing

✪ 9-18V DC power supply

* Digital to analog; actual data may vary depending on usage scenarios

Specifications

Effects Digital Audio Signal Processing

24-bit depth, 44.1kHz sample rate

Frequency Response

20Hz – 20kHz ± 1dB

Dynamic Range

Max. 127 dB (digital to analog)

Effects

460+ (incl. global EQ)

No. of Effect Modules

16

Effects Slots

Total of 12 simultaneous effects slots

Patches

300

Looper Time

Stereo 60 seconds

Bluetooth®

4.2 Dual-Mode (BLE & audio) with Bluetooth® MIDI support

Inputs

One 1/4″ Tip Sleeve (TS) instrument jack with 3 input mode selector

One XLR or 1/4″ (TS) combo jack with 5 input mode selector and mic preamp (max. gain of 52dB)

One 1/8″ Stereo Auxiliary In (Aux In) jack

Two 1/4″ Tip Ring Sleeve (TRS) expression pedal/momentary footswitch input (EXP/CTRL) jacks

One 1/4″ Tip Ring Sleeve (TRS) unbalanced stereo FX loop return jack

One 1/8″ Tip Ring Sleeve (TRS) MIDI input jack

Outputs

Two 1/4″ Tip Ring Sleeve (TRS) unbalanced stereo output jacks

Two XLR balanced stereo output jacks, with ground lift switch

One 1/4″ Tip Ring Sleeve (TRS) unbalanced stereo FX loop send jack

One 1/8″ stereo headphones output jack

One 1/8″ Tip Ring Sleeve (TRS) MIDI output jack

Input Impedance

1/4″ Tip Sleeve (TS) Input: E.GT: 1MΩ; A.GT: 4.7MΩ; LINE: 10kΩ

XLR Input: 5kΩ

FX Loop Return: 100kΩ

Aux In: 10kΩ

Output Impedance

Unbalanced Output: 1kΩ

Balanced Output: 1kΩ

FX Loop Send: 1kΩ

Headphones: 47Ω

Screen

5″ 800 x 480 Color Dynamic Display Touch Screen

USB Port

USB 2.0 Type-C port; Supports USB Audio 2.0; Supports 44.1 to 192kHz sample rate switching

IR Impulse Response/IR processing

Supports 24-bit/44.1kHz Mono WAV files, 1024 and 2048 points; Supports up to 50 user IRs

Power Requirements

9-18V DC Center Negative

Current Consumption

1.4A Max (9V DC)

Dimensions

301mm(W) x 180mm(D) x 58mm(H)

Weight

1895g
