RX-70-4K-ARC

HDBaseT™ 4K UHD Receiver, featuring audio de-embed and ARC/Optical audio return (4K: 70m/230ft | 1080p: 100m/328ft)

Features:

• Class A HDBaseT™ 4K Receiver capable of receiving HDMI transmissions over a single cable Cat5e/6 cable with support for ARC or optical audio return

- 70m/230ft: 4K@60Hz 24bit with chroma subsampling color palette 4:2:0

- 100m/328ft: 1920x1080p HD video@60Hz / 48bit Deep Color

• HDBaseT™ feature set supporting the distribution of 4K and HD video, multichannel HD audio, bidirectional IR and RS-232, PoH remote power and Ethernet passthrough
• Supports all high definition resolutions: 4K (UHD & DCI), 1080p, 1080i, 720p with screen refresh rate support of 24Hz, 30Hz (4K) 50Hz, 60Hz (1080p), 4K@60Hz YUV4:2:0
• HDCP 2.2 compliant
• Audio Return Channel and optical audio return support
• TOSLINK input allows for support of TV models without ARC-over-HDMI functionality
• Includes audio out for source audio de-embed
• Full 3D compatibility up to 1080p - frame packing/ sequential (Blu-Ray) and interlaced stereoscopic (satellite/ cable broadcasts)
• Multichannel audio supports 7.1 DTS Master HD and Dolby True HD
• PoH (Power-over-HDBaseT™) enables the receiver to be remotely powered from the a compatible transmission device for flexible installation options
• Transmits discrete wide-band bidirectional IR control and serial commands together within the HDMI signal over a single Cat5e/6
• Switchable RS-232 port for control or firmware update
• Threaded bushing allow use of both standard and locking DC power plugs
• Visual LED indication for power supply to units, HDBaseT™ signal transmission and reception status and HDCP presence in signal
• Cable termination follows IEEE-568B standards
• Automatically adjusts feedback, equalization and amplification of signal for easy installation
• Energy efficient universal power supply included
• Mounting brackets included

Preliminary features - may be subject to change
