JTS Professional Microphones

Gooseneck mic on heavy base accepts wireless tx in base

Product Code: JP-ST850

Brand
JTS
RRP $289.00


Unit of Measure
EACH



1 Year
Technical Specifications
Brands JTS Professional Microphones
  • Details
  • Downloads

ST-850


The product makes gooseneck microphones go wireless and installation a simple work.

  • The ST-850 is compatible with transmitters such as PT-900B, PT-850B, PT-920B (G), PT-950B and PT-990B.
  • The product works with transmitter’s power.
  • When transmitters are unavailable simply connect the ST-850 to a microphone cable with phantom power. It works as a normal gooseneck microphone.
  • Automatic wired / wireless mode transformation; no switch is needed.



SPECIFICATIONS


Type

  • Back Electret Condenser

Frequency Response

  • 50~18,000 Hz

Polar Pattern

  • Supercardioid

Sensitivity(at 1,000 Hz)

  • Wireless: -66±3dB(0.5mV) 0dB=1V/bar
  • Wired : -56±3dB(1.58mV) 0dB=1V/μbar

Impedance

  • Wireless: 2kΩ / Wired : 100Ω

MAX. SPL for 1% T.H.D.

  • 125 dB

Power Supply

  • Wireless: 5VDC
  • Wired: 12-48 VDC phantom power

Current Consumption

  • Wireless: ≤0.5mA / Wired: ≤5.5mA

Output Connector

  • Wireless: 4P Mini XLR / Wired: 3P XLR (M)

Switch

  • When wireless it works as a mute switch
  • When wired it works as a on/off switch

Gooseneck Length.

  • 312mm

Base Dimension (mm)

  • 110.4mm (W)*65.5mm(H)*149.4mm(D)

Net Weight

  • 1000 grams
