Specifications

Directional characteristics:	Cardioid
Principle of operation:	Pressure gradient
Cartridge type:	Pre-polarized condenser
Frequency range:	20 Hz to 20 kHz
Frequency range, ±2 dB:	40 Hz to 20 kHz
Sensitivity, nominal ±2 dB at 1 kHz:	10 mV/Pa; -40 dB re. 1 V/Pa
Equivalent noise level, A-weighted, re. 20 µPa:	Typ. 18 dB(A) re. 20 µPa (max. 20 dB)
Equivalent noise level, ITU-R BS.468-4:	Typ. 25 dB (correct with the attenuator in 0 dB or -20 dB setting)
S/N ratio (A-weighted), re. 1 kHz at 1 Pa (94 dB SPL):	Typ. 76 dB(A)
Total Harmonic Distortion (THD):	< 1 % up to 139 dB SPL peak
Minimum load impedance:	2 kohm
Dynamic range:	Typ. 121 dB
Max. SPL, peak before clipping:	159 dB
Switchable attenuator:	0 dB / -20 dB
Output impedance:	< 200 ohm
Cable drive capability:	100 m (328 ft)
Output balance principle:	Impedance balancing with Active Drive
Common Mode Rejection Ratio (CMRR):	> 60 dB
Power supply (for full specifications):	48 V Phantom power (± 4 V)
Current consumption:	2.8 mA
Connector:	XLR-3M. Pin 1: shield, Pin 2: signal + phase, Pin 3: - phase
Color:	Matte black
Weight:	158 g (5.6 oz)
Microphone diameter:	19 mm (0.75 in)
Capsule diameter:	19 mm (0.75 in)
Length:	170 mm (6.7 in)
Output voltage, RMS:	> 5 V
Polarity:	+V at Pin 2 for positive sound pressure
Temperature range:	-40 °C to 45 °C (14 °F to 113 °F)
Relative Humidity (RH):	Up to 90 %
Matching tolerance:	± 1 dB
Phase deviation for kit:	< 10°
