Specifications

Directional pattern:	Omni
Principle of operation:	Pressure
Cartridge Type:	24 mm (1 in) condenser w. stainless steel diaphragm
Frequency range, ± 2 dB:	20 Hz - 20 kHz with 4 - 6 dB soft boost at 8 kHz
Sensitivity, nominal, ± 2 dB:	70 mV/Pa;-23.1 dB re. 1 V/Pa
Equivalent noise level, A-weighted:	Max. 8 dB(A) re. 20 µPa
Equivalent noise level, ITU-R BS.468-4:	Max. 20 dB
S/N ratio, re. 1 kHz at 1 Pa (94 dB SPL):	86 dB
Total Harmonic Distortion (THD):	<0.5% THD up to 120 dB SPL peak, <1% THD up to 126 dB SPL peak
Dynamic range:	Typ. 118 dB
Max. SPL, peak before clipping:	134 dB
Output impedance:	<200 Ohm
Cable drive capability:	Up to 100 m (328 ft)
Current consumption:	2.20 mA
Weight:	190 g (6.7 oz)
Capsule diameter:	24 mm (1 in)
Connector:	3-pin XLR-M (Standard P48)

Brands	DPA Microphones
Series	d:dicate
