Elegant and exclusive design

SPECIFICATIONS

• Directional pattern:    Supercardioid
• Principle of operation:    Pressure Gradient
• Cartridge Type:    Pre-polarized condenser
• Frequency range:    20 Hz to 20 kHz
• Frequency range, ± 2 dB:    40 Hz to 18 kHz
• Sensitivity, nominal, ± 2 dB at 1 kHz:    12 mV/Pa; -38 dB re. 1 V/Pa
• Equivalent noise level, A-weighted:    Typ. 16 dB(A) re. 20 µPa (max. 19 dB(A))
• Equivalent noise level, ITU-R BS.468-4:    -
• S/N ratio (A-weighted), re. 1 kHz at 1 Pa (94 dB SPL):    Typ. 78 dB(A)
• Total Harmonic Distortion (THD) at 1 kHz:    < 1 % up to 137 dB SPL peak
• Minimum load impedance:    2 kohm
• Dynamic range:    Typ. 121dB
• Max. SPL, peak before clipping:    142dB
• Output impedance:    100 ohm
• Cable drive capability:    100 m (328 ft)
• Output balance principle:    Impedance balancing
• Common Mode Rejection Ratio (CMRR):    > 40 dB
• Power supply (for full specifications):    48 V Phantom power (± 4 V)
• Current consumption:    3.5 mA
• Color:    Matte black
• Weight:    -
• Microphone Diameter:    19 mm (0.75 in)
• Capsule diameter:    19 mm (0.75 in)
• Output voltage, RMS:    2.2V
• Microphone Length:    -
• Polarity:    +V at Pin 2 for positive sound pressure
• Connector:    XLR-3M. Pin 1: shield, Pin 2: signal + phase, Pin 3: - phase
• Relative Humidity (RH):    Up to 90%
• Temperature range:    -40 °C to 45 °C (-40 °F to 113 °F)
