Studio Monitors

Dynaudio Active Dual 9.5"long throw subwoofer system. 500w amp module

Product Code: DY-18S

Brand
Dynaudio
RRP $3,199.00


Unit of Measure
EACH



Unspecified
Technical Specifications
Brands Dynaudio Professional
Size 9.5" x 2
Speaker Type Studio Monitor
  • Details
  • Downloads

18S

True bass

Adding 18S to your monitors will open up a new world of performance that lets you mix and master with painstaking accuracy… and deliver tracks that translate beautifully to any playback system.

We’ve applied advanced DSP modelling technology that acoustically matches 18S to any Dynaudio Pro Studio Monitor from BM Classic, LYD and upwards, turning two-way systems into three-way set-ups. Its punch is delivered by two of our brand-new MSP+ Hybrid Drive units and a 500W amp for absolute control and power.



Technical specifications

  Measured by the best acousticians in the business.

Specification sheet for
part 2
System: Twin opposed 9,5" driver, closed box, active DSP subwoofer
Analog inputs: 2 x balanced XLR, 2 x unbalanced RCA phono
Analog outputs: 2 x balanced XLR, 2 x unbalanced RCA phono
Frequency Response (±3dB): 16Hz – 230Hz
Max SPL (1m, pair): 110dB
Auto ON/OFF: Yes
Box Principle: Sealed
Low Pass Filter: Adjustable/preset
Phase Adjustment: 0/180 degrees
Specification sheet for Subwoofers part 1
Woofer: 2 x 240mm MSP+ Hybrid Drive
Amplifier: 500W Class-D
AC power input: 100-120V/220-240V 50/60Hz
Standby power consumption: < 0.5W
Maximum power consumption: 490W
Weight: 21.5kg / 45.2lb
Dimensions (W x H x D): 447 x 300 x 268mm
I/O Connectors: XLR balanced/RCA
Dimensions with feet (W x H x D): 447 x 333 x 268mm
Shipping box dimensions (W x H x D): 600 x 450 x 400mm
