  • TKIS-2. VoIP intercom module.

TKIS-2. VoIP intercom module.

Product Code: ZE-TKIS-2

Brand
Zenitel
RRP: POA


Unit of Measure
EACH


Unspecified
Technical Specifications
Brands Zenitel
  • Details
  • Downloads
  • Ordering

The VoIP Intercom Module utilizes the latest technology to create unparalleled audio quality.  Some of the many features include: HD voice quality, Open Duplex, Active Noise Cancellation, Automatic Volume Adjustment, MEMS microphone support, and a 10W Class D amplifier. These features, in conjunction with Vingtor-Stentofon's 70 years of experience with acoustic technology are only a few of the many factors that make our audio quality second to none.

  • Build your own IP Intercom station or Help-Point
  • Make your own 10W IP Speaker
  • Control relay and I/Os over IP
  • Supports AlphaCom, IC-EDGE and SIP (for use with any IPBX)
  • Supports a wide set of IP networking standards
  • ONVIF Compatible
  • Add VoIP/CCoIP to your parking solution, cash point, vending machine, et al
  • Remote software upgrade, configuration and monitoring
  • Powered over Ethernet (PoE)
AUDIO
  • Noise cancelling - suppression of musical noise    YES
  • Noise cancelling - suppression of static noise    YES
  • Noise cancelling - suppression of rapidly changing noise    YES
  • Codecs    G.711, G.722, G.729
  • Frequency range, G.722 Codec    200 Hz – 7000 Hz
  • Audio technology    Modes: Full open duplex, switched open duplex, Adaptive jitter filter, Local tone generator, Audio mixing - 3 channels, Sound level detection (scream alarm), Automatic gain control (microphone), Automatic volume adjustment
  • Internal speaker amplifier    10 W class D
  • Supported microphone technologies    Digital MEMS, omnidirectional microphone. Electret omnidirectional microphone
  • Recommended loudspeaker impedance    8 ohm
HARDWARE
  • Ethernet connector    1 x RJ 45
  • All other connectors    Tool less, spring loaded, vibration proof terminals
  • General inputs and outputs    6 (configurable)
  • Outputs    12mA as LED drivers
  • Change-over relay (NO+NC+COM)    Max: 250VAC/220VDC, 2A, 60W
  • Power options    PoE and or external power supply
  • PoE (power over Ethernet)    IEEE 802.3af standard, Class 0 (0.44W to 12.95 W)
  • External power supply    24 VDC (16 – 48 V)
  • Power consumption    Idle 1.8W, max 12W (depending on volume)
  • Audio line out / induction loop signal    600 Ohm
NETWORKING AND PROTOCOLS
  • Protocols    IPv4 (with DiffServ), SIP, TCP, UDP, HTTPS, TFTP, RTP, DHCP, SNMP, ONVIF, CCoIP® , NTP
  • LAN protocols    Power over Ethernet (IEEE 802.3 a-f) Network Access Control (IEEE 802.1x)
  • Management and operation    HTTP/HTTPS (Web configuration) DHCP and static IP + IC-EDGE. Remote automatic software upgrade. Centralized monitoring
  • Advanced supervision functions    E.g. network test, tone test, status reports
  • SIP support    RFC 3261 (SIP base standard), RFC 3515 (SIP refer), RFC 2976 (SIP info)
  • DTMF support    RFC 2833, 2976 (SIP info)
ENVIRONMENT AND COMPLIANCES
  • Operating temperature range    -40° to 70° C / -40° to 158 ° F
  • Storage temperature range    -40° to 70° C / -40° to 158 ° F
  • Relative humidity    < 95% not condensing
  • EMC    CE and FCC Part 15
  • Certificates    UL 60950-1, cUL 60950-1, CB to IEC 60950-1
OTHER SPECIFICATIONS
  • IP address information    Speaks IP address after system boot (requires connected loudspeaker)
  • Country of manufacture    Poland
  • Dimensions (HxWxD)    32 x 117 x 71 mm
  • Weight    0.1 kg / 0.2 lbs
  • Encapsulation material    ASA plastic
  • DIN-rail clips    Wago 209 (included)
  • Warranty    2 Years standard warranty, extendible up to total of 5 years (additional fee)
