Amplifiers

Power Amplifier 2 X 400W @100V SY800V Australian Monitor

Product Code: AJ-SY800V

Brand
Australian Monitor
RRP $2,439.00


Unit of Measure
EACH


5 Year
Technical Specifications
Brands Australian Monitor
Channel count 2
  • Details
  • Downloads

SY800V


2 x 400W Power Amplifier

100V High Impedance Amplifier

The Australian Monitor Synergy Series SY800V offers contractors a host of practical features and delivers 400 watts @ 100V of power per channel in a space-saving high performance package.

The SY800V is ideally suited to today’s complex multi-zone 100v line systems.


  • 2 x 400W 100V high impedance power amplifier
  • Symmetrical layout - even weight distribution
  • High efficiency toroidal mains transformer
  • Balanced inputs and buffered attenuators
  • 1 dB below output clip indication
  • Dual, twin speed axial fans
  • Multi-role output fault indication
  • Signal ground lift switch
  • Built in limiter circuit
  • High-quality, close-tolerance components throughout

Specification

  • Output Power per Channel: 400W
  • Frequency Response: 50Hz - 20kHz
  • Output Channels: 2
  • THD+N: < 0.5%
  • Output Mode: 100V
  • Signal to Noise Ratio: > 97dB
  • Input Voltage: 230Vac 50-60Hz
  • Input Sensitivity: 1Vrms
  • Mounting: 2RU
  • Cooling: Fan-assisted
  • Warranty: 5 years
  • Product Dimensions:
    • (W x D x H) 482mm x 400mm x 87mm Shipping Dimensions
    • (W x D x H) 540mm x 520mm x 210mm
  • Net Weight: 20 Kg
  • Shipping Weight: 22 Kg
  • GTIN EAN: 9323383012547

Product Documents

No documents available
