Speakers

Dynaudio LYD 8 Nearfield Monitor with 8" Woofer, Black (SINGLE)

Product Code: DY-LYD-8BK

Brand
Dynaudio
RRP $1,589.50


Unit of Measure
EACH


1 Year
Features

LYD 8

The biggest 2-way monitor in the LYD series. LYD 8 is a redefinition of our previous Professional monitors. A redefinition that helps you redefine your artistic expression.

With its 8in MSP woofer and state-of-the-art DSP, LYD 8 provides the kind of performance, precision and bass heft that dreams (and maybe hit albums) are made of. Like the rest of the range, these nearfield monitors let you tune their sound for their position in the room, feature handmade drivers, and contain advanced Class-D amps.
Technical Specifications
Brands Dynaudio Professional
Size 8"
Speaker Type Studio Monitor
  • Details
  • Downloads

Technical specifications

Measured by the best acousticians in the business.

Specification sheet forLYD 8part 2
Max SPL (1m, pair): 112dB
Principle: Bass reflex, rear port
Crossover Frequencies: 3.9kHz
Tweeter: 1inch Soft dome
Mid: N/A
Woofer: 8inch
Dimensions (W x H x D): 234 x 369 x 328mm
Weight: 10.2kg
Sensitivity (85dB @ 1m, free field):
+6dB: 50mV
0dB: 100mV
-6dB: 200mV
Specification sheet for LYD part 1
Amplifier:
Power (Tweeter/Woofer): HF 50W/LF 80W
Type: Class D
Power consumption standby: <0.5 W
Power consumption max.: 100 W
Input voltage: 90 - 264 V AC, 50 - 60 Hz
  XLR balanced
Inputs: RCA unbalanced
Outputs: N/A
Cut-off frequencies -6dB limits:
Bass extension +10Hz: 65Hz - 21kHz
Bass extension 0Hz: 55Hz - 21kHz
Bass extension -10Hz: 45Hz - 21kHz
Free field frequency response: 55Hz - 19kHz
