NetworkHD 500 Series 4K60 4:4:4 JPEG2000 Encoder with USB-C port

SKU: NHD-510-TX

The NHD-510-TX is a powerhouse in AV over IP technology, integrating HDMI and USB-C inputs for unparalleled connectivity with both traditional and modern digital devices. Enhanced with Dante AV-A support for superior audio over IP, HDMI loop-out for local display connectivity, and advanced audio switching capabilities, it stands as an essential component for any high-definition setup. As a 1 Gigabit solution, it confidently supports 4K60 4:4:4 video resolution, ensuring crystal-clear image quality across all applications. Whether upgrading commercial spaces, educational institutions, or secure government facilities, the NHD-510-TX delivers an immersive audiovisual experience with HDR10 and Dolby Vision support, minimal latency, and the ability to connect up to 7 USB devices simultaneously. This device is designed to meet the rigorous demands of any complex installation, offering a versatile, high-performance solution for contemporary AV challenges.

• HDMI/USB-C with 4k@60Hz (4:4:4) and HDCP 2.3 compliance over Gigabit network.
• Supports full function USB-C for video/audio/USB data (Data USB 2.0)
• HDMI Video Loop out from active video input
• Ethernet or Fiber connections (550m w/ OM3 MMF or 10km with SMF)
• Ability to auto switch between USB-C and HDMI inputs for encoding
• Dante AV-A available (license required)

HDMI AND USB-C INPUT
The NHD-510-TX revolutionizes input management with intelligent HDMI and USB-C ports that automatically switch between sources, ensuring seamless transitions during presentations or collaborative sessions. This auto-switch feature simplifies the user experience by automatically selecting the active input, making it effortless to manage multiple devices in dynamic AV environments.

HDMI 2.0 ENCODING
Capable of encoding full HDMI 2.0 content. This includes 4K60 4:4:4 8bit and high dynamic range video including Dolby Vision, HDR10 & HLG up to 12bit 4:2:2 at 60Hz

NETWORKHD TOUCH
The 500s series in fully compatible with the intuitive NetworkHD Touch control app for iPad and Android tablets. Effortlessly control matrix and video wall switching with high-definition preview streams of each encoder’s source. Control couldn’t be easier with a drag-and-drop intuitive interface all for free!

ULTRA-FAST SWITCHING
Immediate Content Switching in Less Than 1 Second. Experience the pinnacle of efficiency with the NHD-510-TX’s ultra-fast switching capability, enabling transitions between sources in less than 1 second. This feature is crucial for environments that require quick changes without interruption, offering a virtually seamless experience for users and viewers alike, ensuring that presentations, broadcasts, and collaborative efforts proceed smoothly and without delay.

DANTE AV-A
Elevate your audio distribution with the NHD-510-TX’s support for Dante AV-A, featuring 2×2 channels of high-quality audio over IP on dedicated Dante ethernet port.(license required)

ULTRA-LOW LATENCY 3MS!
3ms when in passthrough mode allows content to be distributed without any perceivable delay.

POWER ROUTING
All signals including audio, video, USB and control signal can be discretely routed and independently assigned between encoders and decoders.

Features

• Supports multi-channel audio passthrough including DTS:X & Dolby Atmos
• Hugely scalable I/O, utilizing multicast technology
• CEC One-Touch Play & Standby, bidirectional IR or RS-232 control of connected devices
• Custom “No Source” idle image upload for branded down time
• Analog audio de-embed output with volume control
• Batch firmware update and batch settings functions offers a massive reduction on installation times
• Custom EDID management with import/export

Technical Specifications

Additional Features

• Audio and Video
• Inputs/Outputs
  • 1x HDMI In
  • 1x USB-C in
  • 1x HDMI loop out
  • 1 x 5-pin Balanced Analog Out (de-embed from active input)
• Maximum Pixel Clock
  • 600Mhz
• Max Video Resolutions
  • 4096x2160p @ 60Hz 8bit 4:4:4 or RGB
  • 3840x2160p @ 60Hz 12bit 4:2:2 Dolby Vision
  • 3840x 2160p @ 60Hz 10bit 4:2:2 HDR10/HLG
  • 1920x1080p @60Hz 12bit
• Output Video Encoding
  • JPEG 2000
• Encoding Data Rate
  • Max: 850Mbps (configurable)
• Stream Preview
  • Up to 720P preview stream.
• End to End Latency
  • 3ms video latency (pass-through mode)
• Supported Standards
  • RGB | BT.2020 | BT.709 | DCI | HDR10 | HDR10+ | HLG | Dolby Vision

COMMUNICATION AND CONTROL

• HDMI
  • HDMI 2.0b | HDCP 2.2 | CEC | EDID
• Network
  • 1x 1GbE RJ45 for AV stream
  • 1 x 1Gbps SFP (1000BaseT-SX: 550m using OM3 multi-mode)
  • 1 x 1GbE RJ45 for Dante AV-A or network connectivity of attached source devices
• RS-232
  • 1x 4-Pin Phoenix Connector | 2-way | API Programmable
• USB
  • 1x USB 2.0 Type Host
• Security Protocols
  • AES 128 | SSH | TLS | HTTPS

POWER

• Power Supply
  • 20V 6A | 802.3af PoE Compliant

In the Box

• 1x NHD-510-TX Encoder
• 1x Pair of Rack Brackets
• 1x Pair of Wall Brackets
• 1x 4-pin Terminal Block
• 1x Quickstart Guide
