  • Dynaudio CORE 47 - 3-Way Nearfiled/Midfield Monitor with 7" Woofer - Dark Grey -Right

Dynaudio CORE 47 - 3-Way Nearfiled/Midfield Monitor with 7" Woofer - Dark Grey -Right

Product Code: DY-CORE-47-R

Brand
Dynaudio
RRP $4,999.50


Unit of Measure
EACH



1 Year
Technical Specifications
Brands Dynaudio Professional
Size 7"
Speaker Type Studio Monitor
  • Details
  • Downloads

Technical specifications

Specification sheet for Core part 2
Tweeter:1in
Midrange:4in
Woofer:7in
Inputs:Analogue and AES3 digital inputs (no sample-rate conversion)
Resolution:Maximum 24-bit / 192 kHz, depending on input signal
 32, 44.1, 48, 96 & 192 kHz sample rates supported, analogue runs at 192 kHz
Max SPL:112 dB @ 1 m anechoic
 118 dB half space
Specification sheet for Core part 1
Crossover frequency:475 Hz (LF/MF) / 5250 Hz (MF/HF)
Frequency response (- 6 dB):37 Hz – 31 kHz
Frequency response (+/- 3 dB):44 Hz – 27 kHz
Box principle:Front-loaded bass reflex
Amplifiers:Pascal Class-D amplifiers: HF 150 W / MF 500 W / LF 500 W
Dimensions:390 mm, 355 mm, 240 mm (W x D x H)
 15 3/8in, 14in, 9 7/16in (W x D x H)
Weight:15.1 kg (33.3 lb)
